Powered by a 15,120 × 6,230-pixel 16K LCD, it delivers sub-20 µm precision with exceptional clarity,
ensuring outstanding quality for demanding applications in dental, jewelry, figurines, micro parts, and ceramic printing.
Ultra Precision Printing = Minimized Defects
16K precision for final product use
Auto Resin Supply & Resin Mixing Blade
Stable continuous printing with auto feed & uniform mixing
Open Material System
- 100% compatible with 3rd-party resins
- Supports Ceramic, Tough & Rigid, HTR, FR, Elastomer resins
Real-time Monitoring
- Real-time monitoring of printer temperature & print status
- Remote access for production control & system diagnostics
SPECIFICATION
212 x 119 x 200mm
Build Volume(W/D/H)
14 x 19μm
Pixel Size(X/Y)
25, 50, 100, 150, 200μm
Layer Thickness
385 / 405nm UV LED
Light Source
16K(15120 x 6230)
Resolution
Pixel Size
385 / 405nm 16K UV LED
16K(15,120 x 6,230)
SOFTWARE
Carima Slicer V2 is an Addtive Manufacturing(AM)
software and boasts its user-friendly UI.
Experience convenient slicing software
specialized for DLP 3D Printers
PERFECT CURING
Supports maximum height of 200mm for
curing work and minimizes thermal deformation
using the UV LED lamp.
